TEIN Mono Racing Coilovers FOR Honda Civic Type R FD2 - VSB56-K1NS1

TEIN Mono Racing Coilovers FOR Honda Civic Type R FD2 - VSB56-K1NS1

-10%

$2,623.50

$2,915.00

Tax Included

Brand: TEIN

Availability: In Stock

SKU: VSB56-K1NS1

Qty:

Tags: honda , suspension , tein , type-r

Estimated Shipping (Australia)

Shipping shown is an estimate. Final cost calculated at checkout.

Description

Description

TEIN SPORT COILOVER KIT

Part Number: VSB56-K1NS1 | RRP: AUD $2,915.00 (inc. GST) | Stock: Low Stock

⚠️ IMPORTANT NOTES:
• US & UK: Special order only
• Springs must be selected when ordering
• Price includes springs

PRODUCT INFORMATION
PRODUCT NAME	TEIN Sport Coilover Kit
PART NUMBER	VSB56-K1NS1
RRP (inc. GST)	AUD $2,915.00
STOCK	⚠️ Low Stock

FEATURES
SPRINGS INCLUDED	✅ Yes (Selectable rates: 14-18K F / 14-16K R)
DAMPING ADJUSTMENT	✅ Yes (16-level)
FULL-LENGTH HEIGHT ADJUST	✅ Yes
UPPER MOUNT	Camber/Caster Adj (F) / STD (R)
EDFC COMPATIBLE	✅ Yes

🔧 CAMBER/CASTER ADJUSTMENT INFORMATION:
• Front: Camber and caster adjustable upper mounts
• Camber adjustment washers with different offsets are available (sold separately)
• Optional washers (sold separately):
- SPS12-R16100-25: For further positive angle adjustment
- SPS12-R16100-05: For further negative angle adjustment
• 2 eccentric washers per vehicle are required

🎯 SPRING RATE OPTIONS:
• Front Springs: Selectable from 14K, 16K, 18K
• Rear Springs: Selectable from 14K, 16K
• US & UK: Special order only - springs must be selected at time of order
• Price includes springs

🔧 SPRING SPECIFICATIONS

FRONT SPRING

Spring Rate (Default)	896 lbs/in / 16.0 kgf/mm (16K)
Optional Rates	14K (784 lbs/in) / 18K (1008 lbs/in)
Free Length	130 mm
I.D. (Inner Diameter)	Φ65 mm

REAR SPRING

Spring Rate (Default)	784 lbs/in / 14.0 kgf/mm (14K)
Optional Rate	16K (896 lbs/in)
Free Length	142 mm
Upper Mount	STD (Standard)

📋 VEHICLE FITMENT GUIDE

MAKE	MODEL	YEAR	CHASSIS	GRADE	DROP (F/R)	ADJ RANGE (F)	ADJ RANGE (R)	MARKET
HONDA	CIVIC TYPE R	2007.03-2010.08	FD2	TYPE R	-25mm / -30mm	-89 to +3	-54 to -17	Japan
HONDA	CIVIC TYPE R	2008-2010	FD2	TYPE R	-25mm / -30mm	-89 to +3	-54 to -17	UK

📝 IMPORTANT NOTES:
• FRONT: Camber and caster adjustable upper mounts
• REAR: STD (Standard) mounts
• Front Spring I.D.: Φ65 mm
• US & UK: Special order only - springs must be selected when ordering
• Compatible with Honda Civic Type R FD2 (2007-2010)
• Japan and UK market specifications available

* Specifications are subject to change without notice. Please verify fitment before purchase.
