EXHAUST SYSTEM
Entirely improved in every section, compatible with all the 86/BRZ family! The ultimate evolution form of the legendary Type-80 has reached to a whole lot new stage
All new single-out exhaust to fit all ZN6/ZC6/ZN8/ZC8.
Rather than simply updating the existing design by extending a single section, the new Ti RACING has been fully re-engineered from scratch starting with re-studying every difference of each chassis to deliver the best answer for all pure performance seekers.
The big-mouth design of 80.5mm for the main pipe while securing the maximum ground clearance, achieving 9.15kg of weight reduction compared to the stock system, along with the straight-through structure with precisely tuned sound.
Experience the next level of performance, refined through years of testing and development.
| APPLICATION | P/N | JPY | NOTES |
|---|---|---|---|
| TOYOTA 86 (ZN6) / GR86 (ZN8) SUBARU BRZ (ZC6 / ZD8) SCION FR-S |
441014 | ￥198,000 | *FOR OFF ROAD USE ONLY. |
Ti RACING Titanium Exhaust series has been designed to improve total performance while reducing the sound as much as possible to meet the sound regulation at the tracks, while EXPREME Ti series has been designed just to unleash engine’s true potential and improve the total performance.
 |
 |
 |
||
|
ORIGINAL TITANIUM MATERIAL To ensure and maintain reasonable price, supreme quality and stable supply, this product is made from TOMEI original titanium material which is refined from raw material and made into performance parts all under quality controlled environment. |
END TIP 115mm Slant-cut end tip.Titanium blue with laser marked TOMEI logo on the end tip. They together give it the great appearance and prove the best quality. |
PRECISION WELDS Titanium is known as a difficult material to weld. Its strength, long-life and beautiful appearance all prove the true quality. |
||
 |
 |
 |
||
|
MAIN MUFFLER Large muffler shell with the straight flow structure eliminates problem of sound issues at the track without reducing performance.Stamped TOMEI logo and gradation titanium color on the mirror finished resonator. |
HIGH QUALITY GLASS WOOL Filled with even more glass wool comparing to existing EXPREME Ti series to reduce and tune the sound.High quality long filament glass wool is very durable and prevents aging deteriorations caused by continues high heat and high pressure. |
SOUND REDUCER/SILENCER The kit comes with end silencer baffles that can be attached as needed to comply with various environmental restrictions. |
 |
|
| Ti RACING | GR86 STD M/T | 86 early model STD | ||
|---|---|---|---|---|
| MATERIAL | TITANIUM | STEEL | STEEL | |
| MAIN PIPE DIAMETER | Φ80.5 | Φ60-53-53W | Φ60-53-53W | |
| MAIN SILENCER DIAMETER | Φ152 | Φ275×180 OVAL | Φ350×190 OVAL | |
| SUB SILENCER DIAMETER | Φ120 | – | – | |
| PIPE THICKNESS | 1mm | 1.5mm | 1.2mm | |
| EXIT DIAMETER | Φ115 | Φ110×2 | Φ90/75×2 | |
| FLANGE THICKNESS | 8.0mm | 2.0mm | 2.0mm | |
| FLANGE INNER DIA. | Φ76.3 | – | – | |
| EXHAUST TEST LEVELS |
IDLING:61.8db 5260RPM:85.4db |
IDLING:59.5db 5260RPM:88.5db |
||
|
IDLING:81.4db 5260RPM:107.3db |
IDLING:81.0db 5260RPM:107.7db |
|||
| WEIGHT | 7.15kg | 16.3kg | 17.4kg | |
