RSE Forged Piston RB26DETT 86.50mm CH30.00 (STD/2.8)

Part no. RA202A-NS05BPistons

$2,299.00

Inc. GST · or 4 payments of $574.75 with afterpay zip

Available to order — we'll confirm the ETA after you order
Not sure it fits? WhatsApp us your car — we'll check before you buy.
  • Shipping from $15Flat rate $15 · Signature $30 · Express $25. Final cost at checkout.
  • Genuine Real Speed Engineering partSourced through authorised channels
  • Fitting in Welshpool118 Briggs St · book a fitting

Product details

The RSE Forged Piston RA202A-NS05B is a high-performance piston kit specifically designed for the Nissan RB26DETT engine, commonly found in models such as the Nissan Skyline GT-R R32, R33, and R34. Manufactured by Real Speed Engineering (RSE), this piston set aims to enhance engine durability and performance, making it suitable for both street and motorsport applications.

Product Specifications:

  • Brand: RSE
  • Series Name: FORGED PISTON 86.50MM CH30.00 (STD 2.8)
  • Product Number: RA202A-NS05B
  • Compatible Car: Nissan Skyline GT-R R32, R33, R34
  • Compatible Engine: Nissan RB26DETT

Key Features:

  • Bore Diameter: 86.50 mm (0.5 mm overbore from the standard 86.0 mm)
  • Compression Height: 30.00 mm (matches OEM specifications)
  • Piston Material: Crafted from A4032 aluminum alloy, offering a balance between strength and thermal expansion properties
  • Crown Volume: 10.8 cc
  • Piston Weight: Approximately 368 grams
  • Pin Specifications: 21.0 mm diameter, 60.0 mm length pins, each weighing 106 grams
  • Ring Specifications:
    • Top Ring: 1.20 mm x 3.05 mm
    • Second Ring: 1.20 mm x 3.90 mm
    • Oil Ring: 2.50 mm x 2.95 mm
  • Circlip Inner Diameter: 21.0 mm

Design Highlights:

  • Forged Construction: Utilizes a high-strength forging process, providing superior rigidity and resistance to high combustion pressures compared to cast pistons
  • Optimized Geometry: Features an oval barrel shape, calculated for optimal thermal expansion and piston movement, ensuring appropriate clearance and reduced friction
  • Valve Recess Design: Incorporates valve recesses capable of accommodating 1 mm oversized valves, offering flexibility for performance modifications
  • Thin Ring Design: Designed for use with thin piston rings, minimizing frictional losses and enhancing engine efficiency
  • Complete Kit: The set includes pistons, pins, clips, and rings, all designed to work harmoniously for reliable performance
Brand
RSE
Series Name
FORGED PISTON 86.50MM CH30.00 (STD 2.8)
Product Number
RA202A-NS05B
Compatible Car
NISSAN
Compatible Engine
RB26DETT
Product Description
Bore diameter (mm) 86.50 (OEM +0.5) Pin diameter (mm) 21.0 Pin length (mm) 60.0 Circlip inner diameter (mm) 21.0 Valve recess Yes Compression height (mm) 30.00 (OEM ±0.0) Crown volume (cc) 10.8 Piston weight (g) 368.0 Pin weight (g) 106.0 Total weight (g) 474.0 Top ring (mm) 1.20 x 3.05 Second ring (mm) 1.20 x 3.90 Oil ring (mm) 2.50 x 2.95 Material A4032
Notes
Images are for illustration purpose only. Actual product may vary.
